Feature



 Y axis with double motor driving ensures stable and smooth movement of the machine.

 High precision rack gear transmission ensures fast speed and high accuracy.

 Imported linear square guide rail ensures high accuracy and maximum work load.

 Adopt vacuum system, made by advanced international technology, configured with vacuum pump of strong absorption, can absorb different size materials.

 Humanized design of vacuum table with T-slot and clamps, can absorb or clamp the material, the operation is convenient.

 Intelligent protection of working table can avoid damage resulted from the wrong operation. Intelligent  overrunning protection can avoid mechanical collision when set graphic exceeds processing size.

 Automatic lubrication system fulfills the periodic lubrication maintenance just by one single touch.

Application



This kind of machine is widely used in 3D carved plates with wave patterns, cabinet door, solid wooden door, craft wooden door, non-painting wooden door, screen, craft windows, computer desk and the panel furniture auxiliary processing etc.

Technical Parameters



Clarico-Full Image
Download
The following technical details are issued to the best of our knowledge, however, without any responsility for results due to several different kinds of material and application processes. Therefore, we highly recommend that before every usage a test should be conducted on the original material.
Data sheet

Clarico-Image-Text

Bal screw_High working efficiency


 Balls are rotating inside the Ballscrew nut to offer high working efficiency.

 It is easy to transmit linear motion into rotation motion.


Automatic lubrication


 The lubrication time period can be set in the software, to ensure the accuracy of transmission system, operator just need to set up the time break in the software and keep the oil container full.

Clarico-Text-Image
Clarico-Image-Text

Broche HSD Italy


 Power S1/S6: 3Kw/6Kw

 Connection type: Collet ER32

 Rated voltage: 380V

 Rated speed: 18.000 rpm

 Max speed: 18.000rpm

 Rotation: Right

Rack & Pinion System _ YYC


 Ensure the transmission high precision, high speed and high stability.
Clarico-Text-Image
Clarico-Image-Text

DSP control system


 DSP A11

 Linear Guideway


 The PMI linear guideway is a design of rolling motion with a low friction coeffi cient, and the diff erence between dynamic and static friction is very small.

 Therefore, the stick-slip will not occur when submicron feeding is making.

Clarico-Text-Image

Options



Machine working samples
