Technical Parameters

Download

The following technical details are issued to the best of our knowledge, however, without any responsility for results due to several different kinds of material and application processes. Therefore, we highly recommend that before every usage a test should be conducted on the original material.

Data sheet

Laser source _ Raycus

Direct control of all the fiber laser functions, Synchronized control of the laser source.

High speed perforation.

Cutting data library.

More than 100,000 hours work-life of pumped diode, almost free maintenance.

Servo Motors and drivers _ FUJI

The FUJI servo motors enjoy fast dynamic response and stable performances. It has high inertia and large torque, output with strong power.

Laser Cutting Head _ Raytools

Collimating lens and focal lens adopt compound lens, to obtain the optimal optical quality and the cutting effect.

Completely sealed internal structure of the laser head can avoid optical parts polluted by dust.

Guide Rail _ HIWIN

W ear resisting.

Higher speed and Stable performance.

Noise volume is lower.

High accuracy and long service life.

Rack & Pinion System _ YYC

Ensure the transmission high precision, high speed and high stability.

Water Cooling System

Dual cooling function: laser source cooling; laser head cooling.

Multiple protection functions, passive alarm terminals and remote control terminals, easy to achieve centralized CNC control and monitoring.

Automatic lubrication

The lubrication time period can be set in the software, to ensure the accuracy of transmission system, operator just need to set up the time break in the software and keep the oil container full.

Smoke Exhausting System

Remove the smoke and dust caused from metal processing.

Electric Components _ France Schneider

Circuit protection against short-circuit currents, overload currents, breaking and industrial disconnection as per standards IEC/EN 60947-2.

Proportional Valve _ Japan SMC

Stepless control of air pressure proportional to an electrical signal.

Serial communications specifications.

Compact / light weight (Integrated communication parts).

Solenoid Valve _ Taiwan AIRTAC

Ultra High Pressure Solenoid Valve support up to 3Mpa, fast on-off response speed.

Planetary Gearbox _ Motoreducer

Excellent Performances, high torsional stiffness,low noise, low backlash.

Satellite gears are double-supported on hardened and groundshafts with full-complement needle bearings increasing torsional stiffness.

Available Functions

Software

Support AI/PLT/Gerber formats, accept Mater Cam, Type3 output international standard G code.

Lead-in/out, cutting compensation, micro-joint, bridging, back entry, gap cutting etc...

Multiple piercing methods available, separated laser power/frequency/ gas type/ gas pressure/ height track can be set during cutting and piercing.

WIFI remote control panel.

Leapfrog function

Highly improve the cutting efficiency.

Photoelectric edge search

Fast location and improve processing efficiency.

Power control

Allowing corners to be cut with a sharp angle.

Flying cut

Especially for thin metal sheet, fast cut of matrix patterns.

Sprint laser piercing

This helps to keep the optics clean and improves the cutting process by pushing vaporized and liquified material out through the kerf, especially for the thick sheet metal.
